Body Controller Software
127
A19 Lift Retracted Proximity Switch (Input %IX2.07)
This circuit monitors the ON/OFF status of the Lift Retracted Switch. This input is ON when the Lift is in the stowed position.
Function Logic:
Input Device
Status
I/O Address
Status
Lift Retracted Prox. Switch
Activated
%IX2.07
ON
4.05: Multi-Function Inputs
B01 Not Used (Input IX0.00)
This circuit is not used.
Related Option Configurations
Option
Status
Functionality
N/A
OFF
N/A
Function Logic:
Input Device
Status
I/O Address
Status
N/A
N/A
%IX0.00
N/A
B02 Hydraulic Oil Temp. Sensor (Input IX0.00)
This circuit monitors the hydraulic oil temp sensor. This is an analog sensor with a voltage range of 0.5-4.5VDC. The temperature
range for the sensor is -580 to 3020 degrees F.
Related Option Configurations
Option
Status
Functionality
Oil Temp Sensor
ON
Input %IX0.00 Is Used as Oil Temp Signal
Function Logic:
Input Device
Status
I/O Address
Status
Hydraulic Oil Temp
Temp = ((3600/4) * (Volts-0.5))-580
%IX0.00
0.5-4.5Volts
B03 Lift Lowered Proximity Switch (Input %IX0.06)
This circuit monitors the ON/OFF status of the Lift Lowered proximity switch. This circuit is only used in a PYTHON unit. This is
ON when the Lift arm is in the Lowered position.
Related Option Configurations
Selected Truck
Status
Functionality
Python
-
Input %IX0.06 Is Used as Lift Lowered Prox.
Function Logic:
Input Device
Status
I/O Address
Status
Lift Lowered Proximity Switch
Activated
%IX0.06
ON
