Body Controller Software
129
Transmission Temp. Switch
Activated
%IX0.13
ON
B08 Rear Strobe In-Cab Enable (Input %IX1.07)
This input is controlled by the strobe light switch in the control panel and is used to enable Tailgate mounted strobe lights.
Related Option Configurations
Option
Status
Functionality
Low Hyd. Oil Ind.
OFF
Input %IX1.07 Is Used as Rear Strobe Sw.
Republic
OFF
Function Logic:
Input Device
Status
I/O Address
Status
Strobe Light In-Cab Enable
Activated
%IX1.07
ON
B09 Turn Signal Light Enable (Input %IX1.07)
This circuit monitors the status of the Turn Signal Light enable circuit. This circuit is used for disabling Front Strobe, Rear Strobe
and Veolia strobe circuits. This circuit can be used only in Non-MULTIPACK units.
Related Option Configurations
Option
Status
Functionality
Low Hyd. Oil Ind.
OFF
Input %IX1.07 Is Used chassis turn signal and disables Rear Strobes.
Republic
ON
Function Logic:
Input Device
Status
I/O Address
Status
Turn Signal Enable Circuit
Activated
%IX1.07
ON
B10 Oil Level Switch (Input %IX1.07)
This circuit monitors the status of the Oil level switch in the Hydraulic tank. The switch is ON when the hydraulic oil level is good.
Related Option Configurations
Option
Status
Functionality
Low Hyd. Oil Ind.
ON
Input %IX1.07 Is Used as Low Oil Sensor.
Republic
OFF
Function Logic:
Input Device
Status
I/O Address
Status
Oil Level Switch
Activated
%IX1.07
ON
B11 Body Down Proximity (Input %IX2.01)
This circuit monitors the ON/OFF status of the Body Down Proximity Switch. The input is ON when the body is down. This circuit
can be used only in NON-MULTIPACK units.
Related Option Configurations
Option
Status
Functionality
