Selected Truck Type
7000 OIN
Input %IX2.01 Is Used as Body Lowered Prox.
Selected Truck Type
7000 OIGAI
Input %IX2.01 Is Used as Body Lowered Prox.
Selected Truck Type
Python OIGAI
Input %IX2.01 Is Used as Body Lowered Prox.
Function Logic:
Input Device
Status
I/O Address
Status
Body Down Proximity
Activated
%IX2.01
ON
B12 Tailgate Buzzer Push Button (Body Input %IX2.01)
This circuit monitors the ON/OFF status of the Tailgate/helper Buzzer switch. This switch activates the In-Cab Alarm and used in
MULTIPACK units only.
Related Option Configurations
Option
Status
Functionality
Selected Truck Type
Multipack OIGAI
Input %IX2.01 Is Used as Tailgate Buzzer Switch
Function Logic:
Input Device
Status
I/O Address
Status
Tailgate Buzzer Switch
Activated
%IX2.01
ON
4.02: Standard Output Functions
C01 Rear Strobe Light (Output %QX0.00)
This circuit operates the Rear Strobe light circuit.
Related Option Configurations
Option 1
Status
Functionality
Republic
OFF
Input %IX1.07 Is Used as Rear Strobe Enable Circuit
Low Hyd. Oil Ind.
OFF
Option 2
Status
Functionality
Republic
ON
Input %IX1.07 Is Used as Turn Signal, Rear Strobes are disabled with
chassis turn signal
Low Hyd. Oil Ind.
OFF
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
Optional Rear Strobe Enable Circuit
Activated
%IX1.07
ON
B
OR
Hydraulic Pumps Enabled
Activated
%IX1.05
ON (momentary)
C
OR
Chassis Reverse
Activated
J1939 gear
ON
Note: Conditions (A OR B OR C) true, will activate the Rear Strobe circuit.
C02 Packer Pump (P2) (Output %QX0.02)
This output function controls the Packer Pump (P2).
