Body Controller Software
132
Note: With the hydraulic system enabled and, condition (A AND B) true, OR C true, will activate (Packer Pump).
Selected Truck Type (PYTHON)
Option Configurations
Low Torque Limit
ON
Input %IX0.12 (Low Torque Press Sw.) disengages Pump 2
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
Packer Extend Solenoid
Activated
%QX0.04
ON
B
OR
Packer Retract Solenoid
Activated
%QX0.05
ON
Speed Parameters
Default Setting
Maximum Vehicle Speed
25 MPH
Maximum Engage Engine Speed
1500 RPM
Maximum Operating Engine Speed
3000 RPM
Note: Condition (A OR B), will keep Condition C (Packer Pump) activated in Python mode.
Selected Truck Type (Multipack)
Option Configurations
Low Torque Limit
ON
Input %IX0.12 (Low Torque Press Sw.) disengages Pump 2
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
Packer Extend Solenoid
Activated
%QX0.04
ON
B
OR
Packer Retract Solenoid
Activated
%QX0.05
ON
C
OR
Chassis Neutral
Activated
%IX1.04
ON
D
OR
Tailgate Control Prox.
Activated
%IX2.2
ON
E
OR
Throttle Advance Switch
Activated
%IX0.6
ON
Speed Parameters
Default Setting
Maximum Vehicle Speed
25 MPH
Maximum Engage Engine Speed
1500 RPM
Maximum Operating Engine Speed
3000 RPM
Note: With condition (A OR B OR C OR D OR E) true, will keep the Packer Pump activate in Multipack mode.
C03 Lift Retract Solenoid (Output %QX0.03)
This output function controls the Lift Retract function for the Python Auto-Lift. The standard Python lift has two modes for lift
operation, Auto-Lift mode and Manual mode. To toggle the control between the two modes, press and hold the Grabber Close and
Grabber Open buttons simultaneously for five seconds or until the in-cab alarm stops sounding. Additionally, the Coordinated Dump
option must be turned ON for Auto-Lift to functions.
Related Option Configurations
Option
Statu
Functionality
