Body Controller Software
133
s
Coordinated Dump
ON
Enables Auto-Lift
Lift Stow
ON
Enables Lift Auto Stow
Condition
Modifiable Parameters
Default Setting
A
Grabber Close Time
1.74 Sec.
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
Auto-Lift
ON
N/A
B
AND
Joystick Enable
Activated
C
AND
Grabber Close Button
Activated
%IX2.06
ON
D
AND
Grabber Open Button
Deactivated
%IX0.01
OFF
E
AND
Grabber Close Time
Expired
%QX0.10
ON 1.4 Seconds
OR
A1
-
Lift Stow
ON
N/A
N/A
A2
AND
Grabber Close Button
Activated
%IX2.06
ON
A3
AND
Grabber Open Button
Deactivated
%IX0.01
OFF
Note: This Output can be used in MULTIPACK and PYTHON units. The lift retract solenoid is used to retract the lift during the
dumping of a container or during stowing of the lift.
C04 Packer Retract Solenoid (Output %QX0.4)
This output function controls the Packer Retract circuit. There are two modes for packer operation i.e., Auto mode and Manual
mode. To toggle the control between Auto mode and Manual mode, turn ON the System Power switch, press and hold the Extend
and Retract buttons simultaneously for five seconds or until the In-Cab Alarm stops sounding. With the Tailgate open the Packer
will operate in manual mode only.
Condition
Modifiable Parameters
Default Setting
A
Packer Pressure Switch Time
7 Seconds
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
Auto Pack
Extending
%QX0.5
ON
B
AND
Packer Full Extend Prox. Sw.
Activated
%IX0.04
ON (momentary)
C
OR
Packer Pressure Sw.
Deactivated
%IX2.05
OFF
D
OR
Packer Extend Timeout
Expired
%QX0.5
ON 30 Seconds
E
AND
Packer Extend PB
Deactivated
%IX0.14
OFF
OR
-
Manual Pack
ON
N/A
N/A
A1
AND
Grabber Close Button
Activated
%IX2.06
ON
