Body Controller Software
134
A2
AND
Grabber Open Button
Deactivated
%IX0.01
OFF
Note: During the Auto-Pack cycle (condition A true), condition ((B OR C OR D) AND E) will activate the output.
Retract function can be manually operated by pressing the Retract button (A1 AND A2) . Condition ‘E’ will initiate a Retract action
during an Auto-Pack cycle.
C05 Packer Extend Solenoid (Output %QX0.05)
This output function controls the Packer Extend circuit. There are two modes for packer operation Auto and Manual. To toggle the
control between Auto and Manual modes, turn the System Power switch ON, press and hold the Packer Extend and Retract buttons
simultaneously for five seconds or until the In-Cab alarm stops sounding. With the Tailgate open the packer will operate only in manual
mode.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions necessary to activate the circuit
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
System Power Switch
Activated
%IX0.15
ON
AND
Hydraulic Pump Enable PB
Enabled
%IX1.05
ON (momentary)
AND
Packer Retract Button
Deactivated
%IX1.06
OFF
AND
B
AND
Packer Retract Button
Deactivated
%IX1.06
OFF
AND
Packer Pressure Switch
Activated
%IX2.05
ON
AND
Packer Full Extend Proximity Switch
Deactivated
%IX0.04
OFF
AND
Tailgate Closed Proximity
Activated
%IX0.03
ON
AND
C
Packer Extend Push Button
Activated
%IX0.14
ON (momentary)
OR
D
Grabber Open PB, Select-O-Pack Start
Activated
%IX0.1
ON
Note: With the conditions (A AND B) true, Function (C OR D) activates the Packer Extend Solenoid.
C06 Lift Raise Solenoid (Body Output %QX0.07)
This output function controls the Lift Raise function for the Python Auto-Lift. The standard Python lift has two modes for Lift
operation, Auto-Lift mode and Manual mode. To toggle the control between the two modes press and hold the Grabber Close and
Grabber Open buttons simultaneously for five seconds or until the In-Cab alarm stops sounding.
Condition
Modifiable Parameters
Default Setting
A
Grabber Close Time
1.74 Sec.
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Grabber Close Button
Activated
%IX2.06
ON
B
and Grabber Open Button
Deactivated
%IX0.01
OFF
