Body Controller Software
135
Note: This Output can be used in MULTIPACK and PYTHON units. With Condition (B AND C) true condition A will activate the Lift
Raise output. With Auto-Lift mode enabled the Grabber Close button will close the Grabber for the duration of the Grabber Close Time,
then trigger the Lift Raise and Retract functions to bring the lift into the dump position.
C07 Filter Bypass Indicator (Output %QX0.08)
This output function controls the Filter Bypass Indicator. Activation of this light indicates that the filter is or has been in bypass,
within the past fifteen minutes. The light will turn ON for 1 second for every hour for the 1
st
5 hours that the filter is in bypass. (i.e.
During the first hour the light will flash for 1 second then pause for 11 seconds, During the second hour the light will flash for 2 seconds
then pause for 10 seconds Etc.). Once the accumulated time has reached the “Start Filter Warning” that is, once the bypass time reaches
5 hours’ time the indicator will become continuous.
This sequence will continue until the 6
th
hour when the light will turn ON continuously and Fault #32 will be set. At this point the pump
will shut OFF i.e. Once the accumulated time reaches the “Start Filter Shutdown” time the hydraulic pump will be disengaged, and the
indicator will flash continuously. Under this condition, the pump will only be allowed to operate in 3-minute intervals. Turning the
System Power Switch OFF then ON again will reset the 3-minute time interval. The pump will continue to operate in this fault mode until
the hydraulic filter has been serviced and is no longer bypassing oil. Once the filter has been changed the light will stay ON until the
pump has run for 30 minutes with a clean filter.
Start Filter Shutdown Warning
Conditions Necessary to activate the circuit:
and Filter Pressure Switch
Note: With condition ‘A’ true, condition (B ORC) will activate the Filter Bypass Indicator output.
These conditions indicate that the Filter is in Bypass. Each time this condition occurs the indicator will continue the flash sequence for
15 minutes after bypass conditions have subsided. Under cold weather conditions, the hydraulic filter may go into bypass when low
oil temperatures create a high oil viscosity. This will subside when the hydraulic system reaches operating temperature.
C08 Lift Extended Indicator (Output %QX0.09)
This output function controls the lift extended indicator.
Conditions Necessary to activate the circuit:
Lift Retracted Prox. Switch
