Body Controller Software
136
Note: With condition (A OR B) true, the Lift Extended Indicator will be activated.
C09 Tailgate Open Indicator (In Cab Output %QX0.12)
This output function controls the Tailgate Open indicator light.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Tailgate Closed Proximity Switch
Deactivated
%IX0.03
OFF
Note: With conditions (A) true, the Tailgate Open indicator will activate.
C10 Lift Pump (P1) (Output %QX0.14)
This output function controls Hydraulic Pump (P1), the Lift Pump.
Related Option Configurations
Option
Status
Functionality
Selected Truck Type
Python OIGIA
Configures controller for DPF Python, Operate in Gear at Idle
Selected Truck Type
Multipack OIGIA
Configures controller for DPF Multi-Pack, Operate in Gear at Idle
Parameters
Default Setting
Range
Max.Spd Lift Operate
7 MPH
1 to 12 MPH
Max.Spd Hyd. Pump
25 MPH
1 to 45 MPH
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
System Power Switch
Activated
%IX0.15
ON
AND
Hydraulic Pump Enable PB
Activated
%IX0.04
ON (momentary)
AND
Selected Truck Type (PYTHON) OR (Multi-Pack)
B
OR
Chassis Service Brake
Applied
%IX2.04
ON (900 rpm max)
C
OR
Chassis Transmission
In Neutral
%IX1.04
ON (1350 rpm max)
D
OR
Packer Extend Solenoid
Activated
%QX0.05
ON (1350 rpm max)
Selected Truck Type (Multipack)
E
OR
Tailgate Control Prox..
Slide Active
%IX2.02
ON (1350 rpm max)
F
OR
T/G Throttle Advance Switch
T/A Toggle
%IX0.6
ON (1350 rpm max)
