Body Controller Software
138
D01 Body Raised Indicator (Output %QX0.01)
This output function controls the Body Raised Indicator light
Related Option Configurations
Option
Status
Functionality
Body Raise Ind
ON
Input %IX2.01 Is Used as Dump Body Down Prox.
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Body Down Proximity Switch
Deactivated
IX2.01
OFF
Note: With the Body Down Proximity switch deactivated, the Body Raised Indicator will be active.
D02 Throttle Advance (Output %QX0.01)
This output function controls the Throttle Advance signal transmitted to the vehicle’s engine.
Related Option Configurations
Option
Status
Functionality
Selected Truck Type
Multipack OIGAI
Output %QX0.01 Is Used as Tailgate Throttle Advance Switch
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O Address
Status
A
OR
Tailgate Hydraulic Power
Activated
%QX0.06
ON
B
OR
Chassis Transmission
In Neutral
%IX1.04
ON
Note: This control is used only in MULTIPACK unit. With condition (A AND B) true Throttle Advance output will activate.
D03 Tailgate Hydraulic Power (Output %QX0.06)
This output function controls the solenoid activating the Tailgate controls. This output is active only when the Tailgate control
proximity switch is active, or the remote Throttle Advance has been activated.
Related Option Configurations
Option
Status
Functionality
Selected Truck Type
Multipack OIGAI
Output %QX0.06 Is Used as Tailgate Hydraulic Power Sole.
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
System Power Switch
Activated
%IX0.15
ON
AND
Hydraulic Pump Enable PB
Activated
%IX0.04
ON (momentary)
AND
B
OR
Tailgate Control Prox.
Activated
%IX2.02
ON
C
OR
Throttle Advance Sw.
Activated
%IX0.06
ON
Note: This Output can be used only in MULTIPACK unit. With condition (A AND B) true, function (C OR D) will activate the Tailgate
Hydraulic Power output.
