Body Controller Softw are
Copyright 2024, The Heil Co.
Printed in the U.S.A.
Body Controller Software
139
D04 Front Strobe Light (Output %QX0.06)
This circuit operates the Front Strobe light circuit.
Related Option Configurations
Option
Status
Functionality
Front Strobe
ON
Output %QX0.06 Is Used as Front Strobe Circuit
Out of Dim. Signal
Disabled
Republic
ON
Input %IX1.07 Is Used as Turn Signal, Rear Strobes
are disabled with chassis turn signal
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
System Power Switch
Activated
%IX0.15
ON
AND
Hydraulic Pump Enable PB
Activated
%IX0.04
ON (momentary)
OR
B
-
Optional Rear Strobe Enable Circuit
Activated
%IX1.07
ON
OR
C
OR
Chassis Reverse
Activated
J1939 gear
Reverse
Note: Conditions (A OR B OR C) true, will activate the Front Strobe circuit. This Output can be used only in Non-MULTIPACK units.
With conditions (A OR B OR C) true, function (D) will activate the Front Strobe circuit.
D05 Out Of Dimension (Output %QX0.06)
This circuit operates the Front Strobe light circuit.
Related Option Configurations
Option
Status
Functionality
Front Strobe
OFF
Output %QX0.06 Is Used as Out of Dimension Signal
Out of Dim. Limit
Enabled
Selected Truck Type
Python OIGAI
-
1-12 mph
Set Speed for Out of Dimension
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O Address
Status
A
-
Vehicle Speed > Set Speed
N/A
N/A
N/A
AND
B
-
Side Door Closed Prox.
Deactivated
%IX0.02
OFF
C
OR
Lift Extended Indicator
Activated
%QX0.09
ON
D
OR
Body Raised Indicator
Activated
%QX0.01
ON
E
OR
Tailgate Open Indicator
Activated
%QX0.12
ON
Note: With condition (A) true, will activate the Front Strobe circuit. This Output can be used only in Non-MULTIPACK units. With
conditions (A OR B OR C) true, function (D) will activate the Front Strobe circuit.
