Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O
Address
Status
A
-
Grabber Lift Interlock
Activated
N/A
ON
B
AND
Lift Raised Proximity
Activated
%IX0.06
ON
Note: This Output can be used only in 7000 (O.I.G.A.I / O.I.N) units with 3 lever control.
Conditions (A AND B) true, will activate the Grabber open Interlock output. Refer to Section 5.02 for more information on how these
inputs enable/disable auto or manual pack mode. In Auto-Pack mode, condition (B) true will turn ON the Grabber Open Interlock
Solenoid output.
D10 Joystick Enable (Output %QX0.13)
This output function controls the air going to the control joystick/levers.
Related Option Configurations
Option
Setting
Functionality
Selected Truck Type
Python OIGAI
Output %QX0.13 Is Used as Joystick Enable
Selected Truck Type
Multipack OIGAI
Output %QX0.13 Is Used as Joystick Enable
Lift Stow
ON
Enables lift stow feature
Max. Spd Lift Operate
(1-45MPH) Default
7 MPH
Sets the maximum road speed for lift operation
Conditions Necessary to activate the circuit:
Condition
Logic
Function or Component
Status
I/O
Address
Status
A
-
System Power Switch
Activated
%IX0.15
ON
AND
Hydraulic Pump Enable PB
Activated
%IX0.04
ON (momentary)
B
AND
Engine RPM
< 900 RPM
J1939
N/A
C
AND
Chassis Neutral
Activated
%IX1.04
ON
OR
1A
-
System Power Switch
Activated
%IX0.15
ON
AND
Hydraulic Pump Enable PB
Activated
%IX0.04
ON (momentary)
1B
AND
Engine RPM
< 900 RPM
J1939
N/A
1C
AND
Chassis Service Brake
Activated
%IX2.04
ON
1D
AND
Vehicle Speed
< 7 MPH
J1939
N/A
OR
2A
-
System Power Switch
Activated
%IX0.15
ON
AND
Hydraulic Pump Enable PB
Activated
%IX0.04
ON (momentary)
2B
AND
Lift Stow
ON
N/A
N/A
2C
AND
Grabber Open PB
ON
%IX0.01
ON
2D
AND
Grabber Full Open Prox.
Deactivated
%IX2.00
OFF
2E
OR
Lift Retracted Prox.
Deactivated
%IX2.07
OFF
