Body Controller Software
143
Note: This Output is used only in MULTIPACK or PYTHON units.
The output will come ON under three distinct conditions:
1. Pump Enabled (A), Engine Speed < 900 RPMs(B) and the chassis is in Neutral (C). (i.e. stationary operation.)
2. Pump Enabled (1A), Engine Speed < 900 RPMs(1B), chassis Service brake is applied (1C) and vehicle MPH is <7 (1D) (i.e. slowing
down and coming up to a stop.)
3. Pump Enabled (2A), Lift Stow (2B), Grabber Open button (2C), Grabber not fully opened (2D) OR Lift not fully stowed (2E) (i.e.
stowing lift while pulling away from a stop.)
D11 Transmission Temperature Indicator (Output %QX0.13)
This output function controls the Transmission indicator light.
Related Option Configurations
Output %QX0.13 Is Used as Trans Temp Indicator
Conditions Necessary to activate the circuit:
Note: This Output can be used only in 7000 O.I.G.A.I. unit. With condition A true, condition B will activate the Transmission
temperature indicator. The indicator will flash, once per second, when Fault #31 is set. This indicates the transmission fluid temperature
has exceeded a safe operating range.
D12 Throttle Limit (Output %QX0.13)
This output function controls the engine Throttle Limit circuit. Used on operate at idle DPF700 unit
Related Option Configurations
Output %QX0.10 Is Used as Grabber Closed
Conditions Necessary to activate the circuit:
Note: This Output can be used only in 7000 O.I.N. unit. With (A) true, condition ‘B’ will activate the Engine Throttle Limit.
Section 5: Special Features
5.01: Select-O-Pack
Select-O-Pack is a standard feature on all CORTEX controlled Automated side loader products.
This feature automatically cycles the Auto-Pack after a predetermined number of lift cycles.
