Body Controller Software
144
Select-O-Pack Adjustment:
1. Turn the System Power OFF
2. Press and hold the Retract Button for 5 seconds (The beeper will begin to sound at 5 seconds)
3. Each additional activation of the Retract Button will allow one additional lift cycle before automatically packing the
load. With no further activation of the Retract Button performed the Select-
O-Pack function will be disabled.
4. Turn the System Power “ON” to store the setting into memory.
5.02: Auto/Manual Pack Mode
Auto/Manual Pack Mode is a standard feature on all CORTEX Controlled products. While in Auto Mode the packer will
complete its cycle automatically with a momentary activation of the packer extend push button. While in manual mode it will be
necessary to hold the packer extend or retract buttons in order to keep the packer cycling.
Also, while in manual mode all control interlocks will be disabled. This is only intended for special occasions when an
operator needs to bypass the control interlocks.
To toggle the control between Auto and Manual modes press and hold the Packer Extend and
Retract buttons simultaneously until the in-cab alarm stops sounding.
5.03: Python Lift Auto-Lift/Manual Mode
Auto-Lift/Manual Lift Mode is a standard feature on all CORTEX Controlled Python Lifts. With Auto-Lift mode
enabled the Grabber Close button will close the grabber for the duration of the Grabber Close Time, then trigger the lift raise and
retract functions to bring the lift into the dump position.
The Grabber Open button will open the grabber and trigger the lift lower and retract functions to bring the lift into the stowed
position.
To toggle the control between Auto-Lift and Manual modes press and hold the Grabber Close and Grabber Open
buttons simultaneously for five seconds or until the in-cab alarm stops sounding.
5.04: Lift Coordinated Mode
Lift Coordinated Mode is standard on all CORTEX Controlled Python units. While in Auto Mode the lift will automatically
retract and dump when holding the grabber close push button according to the Grab Time parameter (1.74 Seconds is the default:
Grabber Close Time).
To toggle the control between Auto and Manual modes press and hold the Grabber Open and Grabber Close push
buttons simultaneously until the in-cab alarm stops sounding.
5.05: INSIGHT Display Functionality:
CORTEX Controller uses a hand-held device (INSIGHT) for displaying the current status of Input / Output, Engine speed,
Temperatures etc., and can be used to SET / RESET any particular Input / Output bit. This can also be used for configuring or
selecting different options in CORTEX controller.
The basic display terminal with all the function keys is as shown in the figure below.
