D+H BlueKit AIO Basic User Manual

20/40 21/40
230 V, 50 Hz
Seperate electric circuit.
Mark fuse.
Connection - 230 V power supply
L
N
PE
Release opening
for mains plug
COM 2
ADD
COM 1
RT
AL
SD
24 V
M1
Connection - M1 output
Connection of on-site 24 V spring return motor
On-site spring return motors can be connected to the CPL-B using
an RJ45 screw terminal adapter.
1 2 3 4 5 6 7 8
On-site 24 V
spring return motor
Monitoring
+
–
brown
white/brown
green
white/green
orange
white/orange
blue
white/blue
1 2 3 4 5 6 7 8
T-568B
Connection - RJ45 sockets
All components are connected to the central unit via RJ45 cables and connectors.
COM 2
ADD
COM 1
RT
AL
SD
24 V
M1
Corrosion protection:
Apply the supplied contact protection agent to both sides of all RJ45 connectors to protect
them from corrosion.
Patch cable 4x2
AWG26
RJ45 - RJ45
connector
RJ45 - screw terminal adapter
(only connect to CPL-B with RJ45 connector and patch cable)
Terminal assignment CPL-B with adapter
Connection
Adapter
1
2
3
4
5
6
7
8
RJ45 / T-568B
5 (WH/BU)
4 (BU)
1 (WH/OR)
2 (OR)
3 (WH/GN)
6 (GN)
7 (WH/BN)
8 (BN)
M1
Spring return motor
–
Spring return motor
Monitoring
Monitoring
+
Spring return motor
24 V
LSR supply/
24 V output
+ 24 V
–
(GND)
SD
Smoke detector
lift shaft
–
(GND)
–
(GND)
R
(Line)
–
(Line)
–
(GND)
Reset
+ 24 V
+ 24 V
RT
RT/detector, main-
evacuation level
T/R
(Line)
–
(GND)
A
(Alarm)
Z
(Reset)
K
(Control)
S
(Fault)
LT-ZU
L
(not closed)
ADD
Other components
L
(not closed)
–
(GND)
Maintenance
button
close
+ 24 V
Weather
close
open
AL
Fire alarm system
T/R
(Line)
–
(GND)
Reset
(IN)
–
(GND)
COM1
Input / Output 1
Fault
2 COM
Lift
(IN)
HE alarm
3 COM
HE alarm
3
Fault
2
open/closed
1 COM
–
(GND)
open/closed
1
COM2
Input / Output 2
NO contact
4
–
(GND)
NC contact
4
Alarm
(OUT)
COM
4
Lift moves
(IN)
Fault/Maint.
(IN)
–
(GND)
99.829.07 1.2/06/2399.829.07 1.2/06/23
AIO Basic AIO Basic
English
English
