Dr.coffee F08 - Disassemble Brew Motor Group

Rev 0.0
Dr.coffee Service Manual 41
10.2.4 Disassemble brew motor group
Setp 1: Pull out the plug (as shown in figure 1)；
Step 2: Use screwdriver T20 to remove two fixing screws (marked in red as shown in figure 2), grab brew motor group and take out of it.
★ Attention：
1、 Be careful during the disassembly process to prevent scratching your fingers！
2、 Unplug the coffee machine before doing this！
1
4
2
3
Technicup Service Manual
