Ceiling and wall attachment
Dr. Mach
Lamps and Engineering
Room heights H single lamps
Lamps
Hmin*
depending on
ceiling attachment
Hmin**
depending on
lamp head
Mach 120 2450 2575
Mach 120F 2450 2575
Soloflex 2450 2570
Soloflex with handle sleeve 2450 2630
Mach 130 2450 2625
Mach 130 -ster. handle sleeve 2450 2625
Triaflex 2450 2580
Triaflex with cardan bow 2450 2630
Trigenflex 2450 2760
Quintaflex 2450 2825
Mach M3 2450 2862
Mach 380 2450 2862
Mach 400 2450 2897
Mach 500 2450 2867
Tool and instrument trays 2450 2680
* Min. room height in the case of ceiling attachment with shortest suspension tube (180mm)
** Min. room height in case of clearance height of 2000mm under the handle of the lamp
Room heights H single lamps – low room height
Lamps
Hmin*
depending on ceiling attachment
Soloflex with turned joint 2450
Triaflex with turned joint 2450
Trigenflex with fully cardanic joint 2450
Trigenflex with central spring arm 2450
Quintaflex with central spring arm 2450
Mach M3 with central spring arm 2450
Mach 380 with central spring arm 2450
Mach 400 with Space-arm 2520
Mach 500 with Space-arm 2520
* Min. room height in the case of ceiling attachment with shortest suspension tube (180mm)
59500001 Edition 06 11.03.2003 / Bak Page 12/48
