CALL TOLL FREE 1-800-DR-OWNER 25
Figure 15
Adjusting the Cutting Height
WHEN USING THE PTA
FEATURE, INSTALL THE CUTTING CORDS IN ONE OF THE FOUR BOTTOM LINE
PLATES ONLY.
Adjusting the cutting height is easy. Cutting heights range in 1/2-inch increments from 1-1/2 inches when
using the bottom Line Plate, to approximately 4 inches when using the top Line Plate (Figure 14).
Install the Cutting Cords in the Line Plate that gives you the desired cutting height.
The Mow-Ball™
Support
Allow the front end of the machine to rest lightly on the Mow-Ball
Support as you are trimming. The
Mow-Ball
Support should glide on the ground as you maneuver the machine. To achieve the best and
smoothest cut, do not lift up on the Handlebar while operating your DR TRIMMER/ MOWER. Lifting
the Handlebar will force weight down on the Mow-Ball
Support. This uses more energy, slows the
cutting, and produces an unsatisfactory cut. Ideally, the Mow-Ball
Support should lightly rest on the
ground while the wheels balance most of the weight of the machine (Figure 15).
Figure 14
