DR SPRINT User Manual

52 DR
®
TRIMMER/MOWER
Parts List - Axle Assembly - SPRINT

, PRO and COMMERCIAL
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
04 112381 Washer, Flat, 1/4", ZP
08 110761 Nut, Nylon Locking, 5/16"-18
49 151401 Bolt, 1/4"-20 x 3/4", Tri-Lobe (PRO, COMMERCIAL)
50 111581 Bolt, 5/16"-18 x 1", HHCS, GR 2, ZP
83 152331 Nut, Nylon Locking, 7/16"-20, Low Profile
84 147611 Wheel, 16", Black Nylon (PRO)
147601 Wheel, 16", Chrome, Spoke (COMMERCIAL)
190061 Wheel, 14", Black Resin, 6-Spoke (SPRINT)
101 143621 Arm, PTA

Locking
102 143611 Support, PTA

Spring
103 121521 Washer, Nylon, Axle, 3/4" x 3/8" x .020 Thick
104 144011 Spring, E, .500" OD x .075", wire
105 143841 Stud, Pivot
108 147501 Axle Assembly
111 143761 Pivot Support Assembly w/Rod
