54 DR
®
TRIMMER/MOWER
Parts List - Main Frame Assembly - All Models
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
04 112381 Washer, Flat, 1/4", USS
08 110761 Nut, Nylon Locking, 5/16"-18
12 110731 Nut, Nylon Locking, 1/4"-20
28 147521 Frame, Drilled, Aluminum, Orange
(PRO, COMMERCIAL)
190071 Frame, Steel, Orange (SPRINT)
180421 Frame, Drilled, Aluminum, Orange
(SELF-PROPELLED)
45 180811 Washer, Lock, 3/8"
47 111551 Bolt, 3/8"-24 x 3/4", HHCS, GR 2, ZP
49 151401 Screw, 1/4"-20 x 3/4", Tri-Lobe, ZP
50 111581 Bolt, 5/16"-18 x 1", HHCS, GR 2, ZP
51 143941 Spring, Ext., .50" OD x .063" Wire
52 114431 V-Belt, 1/2" x 45", 4L450
53 110751 Nut, Nylon Locking, 3/8"-16
54 144091 Pulley, Idler #2, 2-5/8" OD
55 143771 Shield, Outer, Lower
56 119191 Pulley 4", V-Belt
58 145221 Screw, 3/8"-16 x 1-1/2", HHCS
(PRO, COMMERCIAL)
60 146811 Clip, Mounting, Inner Lower Shield,
(PRO, COMMERCIAL, SELF-PROPELLED)
143801 Clip, Mounting, Inner Lower Shield,
(SPRINT)
61 146781 Shield, Inner, Lower, aluminum
(PRO, COMMERCIAL)
143811 Shield, Inner, Lower, steel
(SPRINT)
179511 Shield, Bottom (SELF-PROPELLED)
62 180131 Bolt, 1/4"-20 x 1", Tri-Lobe, ZP
63 143871 Battery, 12 V, 2.9 Ah
64 143861 Pad, Battery, 1.38" x 7.0"
65 143851 Clamp, Battery, Plastic
66 174881 Engine, B&S, 6.0 HP, E/S
(PRO, COMMERCIAL, SELF-PROPELLED)
190261 Engine, B&S, 5.5 HP, E/S (SPRINT)
67 114921 Bracket, Belt Retainer
68 118731 Nut, Nylon Locking, 10-24
Ref# Part# Description
69 143831 Bracket, Clutch, Deck
70 113071 Pulley, Idler #1, 2-1/4" Diameter
71 143521 Rod, Brake Connecting
72 134431 Bolt, 5/16"-18 x 1-1/2" HCS
73 143751 Washer, Nylon, .505" ID x 1" OD
74 143601 Stand-off, Clutch Arm
75 143581 Arm, Clutch
85 146801 Guide, Engine Pulley, Belt
(PRO, COMMERCIAL, SELF-PROPELLED)
143821 Guide, Engine Pulley, Belt (Sprint)
98 152501 Bolt, 1/4"-20 x 3/4" HCS
99 146821 Rod, Debris Guard,
(PRO, COMMERCIAL)
143791 Rod, Debris Guard (SPRINT)
100 147581 Screw, 10-24 x 1/2", Type B
(PRO, COMMERCIAL)
144511 Bolt, Carriage, 10-24 x 5/8"
(SPRINT – used with item 68)
107 143781 Debris Guard (SPRINT, PRO,
COMMERCIAL)
114 152141 Rivet, Ratchet, 1/4" OD
(PRO, COMMERCIAL, SELF-PROPELLED)
115 146791 Wear Strip (PRO, COMMERCIAL)
Not Illustrated:
114681 Bolt, 1/4"-20 x 1-1/4" HCS
100771 E-Clip, Clutch Cable
(PRO, COMMERCIAL, SPRINT)
152361 Tool, head locking
Labels
127811 Warning, Add Oil
136491 Danger
148221 Danger Head Rotation
148231 Safety Icons
148241 Name, TR2
(PRO, COMMERCIAL, SPRINT)
153071 PTA
(PRO, COMMERCIAL, SPRINT)
153081 Bail Bar
193201 Start, Key Bracket
