56 DR
®
TRIMMER/MOWER
Parts List - Handlebar Assembly - SELF- PROPELLED
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
03 143971 Cable, Throttle, Reverse Throw, B&S
152481 Cable, Throttle, Reverse Throw, Kawasaki
04 112381 Washer, Flat, 1/4" USS
05 113081 Ignition Switch, Key, E/S, w/805 Hardware
06 174561 Handlebar, Lower, Black
07 144641 Bolt, Carriage, 5/16"-18 x 3", GR 2, ZP
08 110761 Nut, Nylon Lock, 5/16"-18
09 147551 Handlebar, Upper, Black
09.1 191911 Handlebar, Upper, Black, w/Grip
10 123361 Bolt, 5/16"-18 x 1-1/4", HHCS, GR 5, ZP
11 174531 Bracket, Key Switch, E/S
12 110731 Nut, Nylon Lock, 1/4"-20
13 101451 Bolt, 1/4"-20 x 1-1/2", HHCS, GR 2, ZP
14 112371 Washer, Flat, #10, USS
15 143681 Bracket, Cable, Trimmer Head Engage, Handlebar
16 189721 Bail Bar
17 143671 Stop, Bail Bar
18 190471 Grip, Handlebar, Textured Vinyl, 18-3/4" Long
19 143931 Spring, C, .720" OD x .063" Wire, Handlebar Adjuster
20 143661 Knob, Handlebar, 5/16"-18
21 191351 Adjuster, Handlebar, Inside
22 143731 Adjuster, Handlebar, Outside
22.1 145801 Adjuster Assembly, Handlebar
23 112141 Tie, Cable, 7-1/2" Long, Black
24 179641 Cable, Transmission
25 114561 Bolt, 1/4"-20 x 2.0", HCS
26 190011 Cable, Trimmer Head Engage
27 179651 Lever, Transmission Engage
Not Illustrated:
188241 Wire Harness, w/adapter
