Polytron 7000 Operation via PROFIBUS PA
PROFIBUS PA:
Coding of the Physical Block Parameter DIAGNOSIS
Octe
t
Bit Mnemonic Description
1 0 DIA_HW_ELECTR Hardware failure of the electronic
1 1 DIA_HW_MECH Hardware failure mechanics
1 2 DIA_TEMP_MOTOR Motor- temperature too high
1 3 DIA_TEMP_ELECTR Electronic temperature too high
1 4 DIA_MEM_CHKSUM Memory error
1 5 DIA_MEASUREMENT Failure in measurement
1 6 DIA_NOT_INIT Device not initialized (No selfcalibration)
1 7 DIA_INIT_ERR Selfcalibration failed
2 0 DIA_ZERO_ERR Zero point error (limit position)
2 1 DIA_SUPPLY Power supply failed (electrical, pneumatic)
2 2 DIA_CONF_INVAL Configuration not valid
2 3 DIA_WARMSTART New-start-up (warmstart up) carried out.
2 4 DIA_COLDSTART Re-start-up (coldstart up) carried out.
2 5 DIA_MAINTAINANCE Maintenance required
2 6 DIA_CHARACT Characterization invalid
2 7 IDENT_NUMBER_VIOLATIO
N
Set to 1 (one), if the Ident_Number of the running cyclic data transfer and
the value of Physical Block IDENT_NUMBER_SELECTOR parameter
are different.
3 0...7 reserved Reserved
4 0...6 reserved Reserved
4 7 EXTENSION_AVAILABLE More diagnosis information is available
Coding of the Physical Block Parameter DIAGNOSIS_EXTENSION
Octe
t
Bit Mnemonic Description
1 0 DIA_SENSOR_ERR Sensor failure
1 1 DIA_OTHER An error has occurred that was not identified.
1 2 DIA_SOFTWARE_ERR The software has detected an error.
1 3 DIA_CALIBRATION_ERR An error occurred during calibration of the device or a calibration error
has been detected during operation of the device.
1 4 DIA_MAINTAINCANCE_SO
ON
Maintenance required soos
