Polytron 7000 Operation via PROFIBUS PA
86
Foundation Fieldbus:
Resource Block and
Transducer Block
BLOCK_ERR: The block error parameter reflects the error status of associated hard-
ware or software components and directly impacts the correct operation of a block.
Block errors will notified as block alarms.
Valu
e
Error Description
0 Other
1 Block Configuration Error
2 Link Configuration Error
3 Simulate Active For the resource block, Simulate Active will be used to indicate that the simulate
hardware jumper is present. An active state (1) of this attribute will indicate that the
jumper is present and that it is possible for the user to enable simulation in an input
or output class function block.
4 Local Override
5 Device Fault State Set
6 Device Needs Mainte-
nance Soon
7 Sensor Failure detected by this block/process variable has a status of BAD, Sensor Failure
8 Output Failure
9 Memory Failure detected by this block/back calculation input has a status of BAD, Device Failure
10 Lost Static Data
11 Lost NV Data
12 Readback Check Failed
13 Device Needs Mainte-
nance Now
14 Power-up
14 Out-of-Service
Transducer block XD_ERROR: An additional parameter, XD_ERROR, must be used to hold the single
error subcode that the manufacturer considers most important when one or more
errors occur. BLOCK_ERR will have bit 0 set whenever XD_ERROR is non-zero.
Valu
e
Error Description
16 Unspecified error An error has occurred that was not identified.
17 General error An error has occurred that could not be classified as one of the errors below.
18 Calibration error An error occurred during calibration of the device or a calibration error has been
detected during operation of the device.
19 Configuration error An error occurred during configuration of the device or a configuration error has
been detected during operation of the device.
20 Electronics Failure An electronic component has failed.
21 Mechanical Failure A mechanical component has failed.
22 I/O Failure An I/O failure has occurred
23 Data Integrity Error Indicates that data stored within the system may no longer be valid due to NVM
checksum failure, Data verify after write failure, etc.
24 Software Error The software has detected an error. This could be caused by an improper interrupt
service routine, an arithmetic overflow, a watchdog timer, etc.
25 Algorithm Error The algorithm used in the transducer block produced an error. This could be due to
an overflow, data reasonableness failure, etc.
