Menu functions
50
Menu functions
The menu can be operated, as desired:
— from the keypad (with integrated display) of the transmitter,
— from a HART-compatible Hand Held Terminal (HHT),
— from a HART-compatible control unit or
— from a Polytron 7000 Palm Pilot 515 (non-Ex version) or
Palm Pilot 515x Ex version.
If the keypad is used, the menus can be operated with the three keys » «,
» « and » « as well as via display.
Key » «
— Use this key to move upwards through the menus.
Key » «
— Use this key to move downwards through the menus.
— If the key is held down for more than 3 seconds, the main menu is opened.
— If the key is held down for longer than 1 second and less then 3 seconds,
the quick menu is opened (the Info menu is displayed without prompting for
a password).
Key » «
— This key is used to confirm inputs and selected menus and functions
Menu structure
Overview: page 51.
The unit has two operating modes: measuring mode and menu mode.
Menu mode contains the menus » Information «, » Calibration « and
» Settings «.
Menu » Information «
The menu » Information « can be opened by any user. However, the user is
unable to make any changes with this menu option.
Menu » Calibration «
This menu permits routine operations needed for the regular maintenance of
the transmitters.
It should be accessible to persons who are responsible for such maintenance.
If the maintenance password is entered, only this menu is accessible.
Menu » Settings «
This menu permits the setting of individual transmitter and sensor parameters.
It should be accessible to authorised persons from the measuring and regula-
tion department or the work safety department. If the password for this menu
is entered, the menu » Calibration « is also accessible.
