Dräger Polytron 7000 User Manual

Technical Data
88
IECEx
– Type P3U & P3FB:
Ex ia IIC T4 Ga (–40
o
C ≤ Ta ≤ +65
o
C)
Ex ia IIC T6 Ga (–40
o
C ≤ Ta ≤ +40
o
C)
Ex ia I Ma (–40
o
C ≤ Ta ≤ +65
o
C)
Ex ic IIC T4 Gc (–40
o
C ≤ Ta ≤ +65
o
C)
Ex ic IIC T6 Gc (–40
o
C ≤ Ta ≤ +65
o
C)
IECEx BVS 04 0003 X
Year of construction (via serial number)
1)
Dräger Safety, 23560 Lübeck, Germany
– Typ P3U : Power supply: U
i
= 30 V, I
i
= 0.3 A, P
i
= 700 mW,
C
i
= 5 nF, L
i
= 50 µH
– Typ P3FB: FISCO Field Device
Power Supply: U
i
= 24 V, I
i
= 0,38 A, P
i
= 5,32 W, C
i
= 5 nF, L
i
= 10
µH
UL (Underwriters Laboratories Inc.)
– Type P3U & P3FB: Only as to Intrinsic Safety for use in Hazardous
Locations
Class I, Div. 1, Groups A, B, C, D
Class II, Div. 1, Groups E, F, G
Use in accordance with Dräger Control Drawing
SE20105.
T4: –40 Ta +65
o
C, T6: –40 Ta +40
o
C.
Not tested in oxygen enriched atmospheres (>21 % O
2
).
– Typ P3U: Power Supply: V
max
= 30 V, I
max
= 0,3 A, P
i
= 700 mW,
C
i
= 5 nF, L
i
= 50 µH
– Typ P3FB: FISCO Field Device
Power Supply: V
max
= 24 V, I
max
= 0,38 A, P
max
= 5,32 W,
C
i
= 5 nF, L
i
= 10 µH
CSA (Canadian Standards Association)
– Type P3U & P3FB: Intrinsic safe
Class I, Div. 1, Groups A, B, C, D
Class II, Div. 1, Groups E, F, G
Use in accordance with Dräger Control Drawing SE20106.
– Typ P3U: Power supply: V
max
= 30 V, I
max
= 0.3 A, P
max
= 700 mW,
C
i
= 5 nF, L
i
= 50 µH
– Typ P3FB: FISCO Field Device
Power Supply: V
max
= 24 V, I
max
= 0,38 A, P
max
= 5,32 W,
C
i
= 5 nF, L
i
= 10 µH
NRTL/C
®
LR97594
