Vigor2912 Series User’s Guide
182
For the detailed configuration, simply refer to
Firewall>>Filter Rule. The firewall filter rules that are not
selected in Firewall>>General>>Default rule can be
available for use in User Management>>User Profile.
External Service
Authentication
The router will authenticate the dial-in user by itself or by
external service such as LDAP server or Radius server. If
LDAP or Radius is selected here, it is not necessary to
configure the password setting above.
Log
Time of login/log out, block/unblock for the user(s) can be sent
to and displayed in Syslog. Please choose any one of the log
items to take down relational records for the user(s).
Pop Browser Tracking
Window
If such function is enabled, a pop up window will be displayed
on the screen with time remaining for connection if Idle
Timeout is set. However, the system will update the time
periodically to keep the connection always on. Thus, Idle
Timeout will not interrupt the network connection.
Authentication
Any user (from LAN side) tries to connect to Internet via
Vigor router must be authenticated by the router first. There
are three ways offered by the router for the user to choose for
authentication.
Web – If it is selected, the use can type the URL of the router
from any browser. Then, a login window will be popped up
and ask the user to type the user name and password for
authentication. If succeed, a Welcome Message (configured in
User Management >> General Setup) will be displayed.
After authentication, the destination URL (if requested by the
user) will be guided automatically by the router.
Alert Tool – If it is selected, the user can open Alert Tool and
type the user name and password for authentication. A window
with remaining time of connection for such user will be
To Next Page
