VigorAP 900 User’s Guide
35
Configuration
private network (Default: 192.168.2.2).
Subnet Mask – Type in an address code that determines the size
of the network. (Default: 255.255.255.0/ 24)
Enable Management VLAN – VigorAP 900 supports tag-based
VLAN for wireless clients accessing Vigor device. Only the
clients with the specified VLAN ID can access into VigorAP
900.
VLAN ID – Type the number as VLAN ID tagged on the
transmitted packet. “0” means no VALN tag.
DHCP Server
Configuration
DHCP stands for Dynamic Host Configuration Protocol. DHCP
server can automatically dispatch related IP settings to any local
user configured as a DHCP client.
Enable Server / Disable Server - Enable Server lets the modem
assign IP address to every host in the LAN.
Disable Server lets you manually or use other DHCP server to
assign IP address to every host in the LAN.
Relay Agent - Specify which subnet that DHCP server is located
the relay agent should redirect the DHCP request to.
Start IP Address - Enter a value of the IP address pool for the
DHCP server to start with when issuing IP addresses. If the 1st
IP address of your modem is 192.168.1.2, the starting IP address
must be 192.168.1.3 or greater, but smaller than 192.168.1.254.
End IP Address - Enter a value of the IP address pool for the
DHCP server to end with when issuing IP addresses.
Subnet Mask -Type in an address code that determines the size
of the network. (Default: 255.255.255.0/ 24)
Default Gateway - Enter a value of the gateway IP address for
the DHCP server.
Lease Time - It allows you to set the leased time for the
specified PC.
DHCP Server IP Address for Relay Agent - It is available
when Enable Relay Agent is selected. Set the IP address of the
DHCP server you are going to use so the Relay Agent can help
to forward the DHCP request to the DHCP server.
Primary IP Address - You must specify a DNS server IP
address here because your ISP should provide you with usually
more than one DNS Server. If your ISP does not provide it, the
modem will automatically apply default DNS Server IP address:
194.109.6.66 to this field.
Secondary IP Address - You can specify secondary DNS server
IP address here because your ISP often provides you more than
one DNS Server. If your ISP does not provide it, the modem will
automatically apply default secondary DNS Server IP address:
194.98.0.1 to this field.
After finishing this web page configuration, please click OK to save the settings.
