VigorAP 900 User’s Guide
67
Channel
Means the channel of frequency of the wireless LAN. The
default channel is 11. You may switch channel if the selected
channel is under serious interference. If you have no idea of
choosing the frequency, please select AutoSelect to let
system determine for you.
Extension Channel
With 802.11n, there is one option to double the bandwidth per
channel. The available extension channel options will be
varied according to the Channel selected above.
Rate
If you choose 11g Only, 11b Only or 11n Only, such feature
will be available for you to set data transmission rate.
Phy Mode
Data will be transmitted via HTMIX mode.
Each access point should be setup to the same Phy mode for
connecting with each other.
Security
Select WEP, TKIP or AES as the encryption algorithm. Type
the key number if required.
Peer Mac Address
Type the peer MAC address for the access point that VigorAP
900 connects to.
Packet-OVERDRIVE
This feature can enhance the performance in data
transmission about 40%* more (by checking Tx Burst). It is
active only when both sides of Access Point and Station (in
wireless client) invoke this function at the same time. That is,
the wireless client must support this feature and invoke the
function, too.
Note: Vigor N61 wireless adapter supports this function.
Therefore, you can use and install it into your PC for
matching with Packet-OVERDRIVE (refer to the following
picture of Vigor N61 wireless utility window, choose Enable
for TxBURST on the tab of Option).
