7. Installation
7.1 Placing the appliance
Separate sections describe dierent ways of placing the appliance. The general description below for placing the
appliance applies to all these sections:
3 Place the appliance on the location where it will be installed and take the following into account:
- The construction dimensions of the appliance (g. 7-2, 7-3, 7-4, 7-5, 7-6 and 7-7).
- The minimum chimney breast dimensions (section 7-8, 7-9 and 7-7).
- There are no combustible objects or materials within the radiation range of the appliance (g. 7-1).
- Place the appliance in such a way that a re hazardous situation can never occur.
- A stable arrangement has been achieved for the appliance to be installed.
When the appliance is placed in an existing open chimney or ue pipe, it is important that it is closed to prevent up and
down air ows. Due to these air ows, the operation of the appliance can be limited.
T
max
100°C
T
max
80°C
≥500
≥200
38C-2861
7-1
