Dru Virtuo Evolve 100 - Page 51

51
Step 4
1  Place log H to the rear left, in front of log E as shown in gure 8-59 and 8-60.Here, it is important that the log falls into the
recess of the glow bed.
1 TakelogIandplaceitdiagonallyinfrontoflogHasshowningure8-59and8-62.
1 PlacelogJtotherearright,infrontoflogFasshowningure8-59and8-61.Thislogliesontherecessintended
forthatpurposeintheglowbed.
1 LogKliesinfrontoflogJ,atthefrontrightinthestoveasshowningure8-59and8-63.
Makesurethatthelogdoesnotmakecontactwiththeslantedprojectionplate.
8-60 8-61
8-62
8-63
8-59
Installation manual
