08
172
In the event of a breakdown
Ensure that the jack is stable. If the
ground is slippery or loose, the jack may
slip or collapse – risk of injury!
Take care to position the jack strictly at
one of the jacking points A or B under
the vehicle, ensuring that the head of the
jack is centred under the contact area of
the vehicle. Otherwise, there is a
risk of
damage to the vehicle and/or of the jack
collapsing – risk of injury!
Fitting a wheel
F Extend jack 6 until its head comes into
contact with jacking point A or B; contact
area A or B on the vehicle must be properly
inserted into the central part of the head of
the jack.
F
Raise the vehicle until there is sufficient
space between the wheel and the ground
to admit the spare (not punctured) wheel
easily.
F Remove the bolts and store them in a clean
place.
F Remove the wheel.
Fitting a steel or "space-saver" type
spare wheel
If the vehicle is equipped with alloy
wheels, the washers do not make contact
with the steel or "space-saver" type
spare wheel. The wheel is secured by the
conical contact of each bolt.
F
Screw in the bolts by hand as far as
possible.
F Pre-tighten the security bolt using
wheelbrace 5
fitted with security socket 2.
F
Pre-tighten the other bolts using wheelbrace
5
only.
F
Put the wheel in place on the hub.
F
Lower the vehicle again fully.
F
Fold jack 6 and remove it.
F
Tighten the security bolt using wheelbrace
5 fitted with security socket 2.
