In the event of a breakdown
Engage the lamp unit in its guides while
keeping it in line with the vehicle.
Tighten sufficiently to ensure sealing, but
without damaging the lamp unit.
Reversing lamps (tailgate)
F Open the tailgate.
F
Remove the access cover and undo the two
lamp unit fixing nuts using a
socket wrench.
F
Squeeze and pull the connector to remove
it.
Once the lamp unit is disconnected and
released, remove the lamp unit so that the
bulbs can be changed:
F
Turn the bulb holder a quarter turn to the left
and pull it out.
F Replace the bulb.
Foglamp (P21W)
F Turn the bulb a quarter turn to the left and
pull it out.
F Change the bulb.
For access, pass your hand under the bumper
on the left-hand side.
F
Turn the bulb holder a quarter turn to the left
and pull it out.
Changing a fuse
Access to the tools
The extraction tweezers are located behind the
fusebox cover.
F Unclip the cover by pulling at the top left,
then right.
F
Remove the cover completely.
F Take the tweezers from their housing.
