In the event of a breakdown
Rear lamps
Model with halogen headlamps
1. Brake lamps/sidelamps (W21/5W).
2. Direction indicators (WY16W amber).
3. Reversing lamps (W16W).
Direction indicators and brake
lamps/sidelamps
Rapid flashing of a direction indicator
lamp (left or right) indicates that one of
the bulbs on the corresponding side has
failed.
Amber coloured bulbs, such as the
direction indicators, must be replaced by
bulbs with identical specifications and
colour.
These bulbs are changed from inside the boot.
F
Open the boot.
F
Remove the access flap on the
corresponding side trim, so that the lamp
unit fixing screw can be accessed.
F
Slacken the lamp unit fixing using a socket
wrench.
F Finish slackening it by hand to recover the
nut, making sure not to let it drop.
F Remove the lamp unit.
F
Unclip the lamp unit connector.
F
Squeeze and pull the connector.
1. Brake lamps/Sidelamps
2. Direction indicators
Once the lamp unit is disconnected and
released, remove the lamp unit so that the
bulbs can be changed:
F
Turn the bulb holder a
quarter turn to the left
and pull it out.
F
Pull the bulb out and replace it.
