08
174
In the event of a breakdown
For the replacement of this type of bulb,
you must contact a
dealer or a qualified
workshop.
Do not touch the "Full LED" technology
lamps – risk of electrocution!
- Side spotlamps.
-
Rear lamps with "Full LED" technology.
-
Third brake lamp.
-
Number plate lamps.
Front lamps
Model with halogen headlamps
1. Main beam headlamps (H7).
2. Dipped beam headlamps (H7).
3. Direction indicators (PWY24).
4. Daytime running lamps (LED).
Halogen bulbs (Hx)
To ensure good quality lighting, check
that the bulb is correctly positioned in its
housing.
Main beam headlamps/Dipped beam
headlamps
F Disconnect the bulb connector.
F
Remove the bulb and change it.
To refit, carry out these operations in reverse
order, directing the bulb's positioning lug
downwards.
Direction indicators
Rapid flashing of a direction indicator
lamp (left or right) indicates that one of
the bulbs on the corresponding side has
failed.
Amber-coloured bulbs must be replaced
by bulbs with identical specifications and
colour.
F Turn the connector a quarter turn anti-
clockwise.
F
Pull the bulb connector.
F Remove the bulb and change it.
Opening the bonnet/Access to bulbs
With the engine warm, proceed with
caution – risk of burns!
Take care with objects or clothing that
could be caught in the blades of the
engine cooling fan – risk of strangulation!
F Remove the protective cover by pulling on
the tab.
