PowerSeries - PC1616/PC1832/PC1864
56
[345]-[346] TLM Failure/Restore Telephone line monitoring trouble/Telephone line restored MA/R E(3)51-000/
R(3)51-000
LT-01/LR-01
[345]-[346] Gen System Trouble/Rest. “Service Required” trouble (view troubles using [*][2])/trouble
restored
MA/R E(3)AA-000/
R(3)AA-000
YX-00/YZ-00
[345]-[346] Gen System Supervisory
Trouble/Rest.
Control panel loses/restores communications with module(s)
connected to the Keybus
MA/R E(3)3A-000/
R(3)3A-000
ET-00/ER-00
[346] Cold Start (System Reset) The system has been restarted after a total power loss. The reporting
code is sent after a 2 minute start-up delay
MA/R R(3)A5-000 RR-00
[347] Phone# 1 or 2 FTC Restoral Control panel has restored communications to central station on
Phone# 1 or 2 (after FTC)
MA/R R(3)54-000 YK-00
[347] Event Buffer is 75% Full Event buffer is almost full since last upload MA/R E(6)22-000 JL-00
[347] DLS Lead In Downloading session start MA/R E(4)11-000 RB-00
[347] DLS Lead Out Downloading session complete MA/R E(4)12-000 RS-00
[347] Zone Fault/Rest. One or more zones have faults/restored MA/R E(3)8A-ZZZ/
R(3)8A-ZZZ
UT-ZZ/UJ-ZZ
[347] Delinquency Programmed amount of time (days or hours) for delinquency has
expired without zone activity, or without system being armed
MA/R E(6)54-000*** CD-00
[347] Wireless Device Low Battery
Trouble/Rest.
Wireless zones, panic pendants, handheld keypads, wireless keys
have low battery/all low batteries restored
MA/R E(3)84-000/
R(3)84-000
XT-00/XR-00
XT-ZZ/XR-ZZ****
[347] Installer Lead In/Lead Out Installer’s mode has been entered/exited MA/R E(6)27-000/
E(6)28-000
LB-00/LS-00
[348] Walk Test End/Begin End of test/Beginning of test T R(6)A7-UUU/
E(6)A7-UUU
TE-00/TS-00
[348] Periodic Test with Trouble Periodic system test transmission with trouble T E(6)A8-000 RY-00
[348] Periodic Test Periodic system test transmission T E(6)A2-000RP-00
[348] System Test [*][6] bell/communications test T E(6)A1-000 RX-00
[349]
PC5700 Ground Fault Trouble/
Rest
Ground/Fault/Trouble occurs on the PC5700 MA/R E(3)1A-000 US-00/UR-00
[349] PC5700 TLM Line 1 Trouble/Rest. TLM Trouble /Restore occurs on the PC5700 MA/R E(3)51-000/
R(3)51-000
LT-01/LR-01
[349] PC5700 TLM Line 2 Trouble/Rest. TLM Trouble /Restore occurs on the PC5700 MA/R E(3)52-000/
R(3)52-000
LT-02/LR-02
[601]-[604] Closings System armed (user 33-95 indicated) O/C R(4)A1-UUU CL-UU
[605]-[608] Openings System disarmed (user 33-95 indicated) O/C E(4)A1-UUU OP-UU
* A/R = alarms/restorals; T/R = tampers/restorals; O/C = openings/closings; MA/R = miscellaneous alarms/restorals; T = test transmissions
** UU = user number (User 01-95); ZZ = zone number (01-64)
*** Use the “Fail to close” event code [(4)54] to report closing or activity delinquency. Ensure the central station is aware that this code is used.
**** Zones are identified, panic pendants, wireless keys, and handheld keypads are not.
Section # Reporting Code Code Sent When...
Dialer
Direction*
Automatic
Contact ID
Codes
SIA Auto
Rep Codes**
Table 2: Contact ID Programmed Zone Alarm/Restoral Event Codes
(as per SIA DCS: ‘Contact ID’ 01-1999): Program any of these codes for zone
alarms/restorals when using the standard (non-automatic) Contact ID reporting
format.
Table 3: Automatic Zone Alarm/Restoral Codes
Medical Alarms
(1)34 Entry / Exit
(1)AA Medical (1)35 Day / Night
(1)A1 Pendant Transmitter (1)36 Outdoor
(1)A2 Fail to Report In (1)37 Tamper
Fire Alarms
(1)38 Near Alarm
(1)1A Fire Alarm
General Alarms
(1)11 Smoke (1)4A General Alarm
(1)12 Combustion (1)43 Exp. module failure
(1)13 Water Flow (1)44 Sensor tamper
(1)14 Heat (1)45 Module Tamper
(1)15 Pull Station (1)4A Cross Zone Police Code
(1)16 Duct
24 Hour Non-Burglary
(1)17 Flame (1)5A 24 Hour non-Burg
(1)18 Near Alarm (1)51 Gas detected
Panic Alarms
(1)52 Refrigeration
(1)2A Panic (1)53 Loss of Heat
(1)21 Duress (1)54 Water Leakage
(1)22 Silent (1)55 Foil Break
(1)23 Audible (1)56 Day Trouble
Burglar Alarms
(1)57 Low bottled Gas level
(1)3A Burglary (1)58 High Temp
(1)31 Perimeter (1)59 Low Temp
(1)32 Interior (1)61 Loss of Air Flow
(1)33 24 Hour
Zone Definition SIA Auto Rep
Codes*
Contact ID
Alarm Auto
Rep Codes*
Contact ID
Rest. Auto
Rep Codes
Delay 1 BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Delay 2 BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Instant BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Interior BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Interior Stay/Away BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Delay Stay/Away BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Delayed 24-Hr Fire FA-ZZ/FH-ZZ E(1)1A-ZZZ R(1)1A-ZZZ
Standard 24-Hr Fire FA-ZZ/FH-ZZ E(1)1A-ZZZ R(1)1A-ZZZ
24-Hr Supervisory US-ZZ/UR-ZZ E(1)5A-ZZZ R(1)5A-ZZZ
24-Hr Supervisory Buzzer UA-ZZ/UH-ZZ E(1)5A-ZZZ R(1)5A-ZZZ
24-Hr Burglary BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
24-Hr Holdup HA-ZZ/HH-ZZ E(1)22-ZZZ R(1)22-ZZZ
24-Hr Gas GA-ZZ/GH-ZZ E(1)51-ZZZ R(1)51-ZZZ
24-Hr Heat KA-ZZ/KH-ZZ E(1)58-ZZZ R(1)58-ZZZ
24-Hr Auxiliary (Medical) MA-ZZ/MH-ZZ E(1)AA-ZZZ R(1)AA-ZZZ
24-Hr Panic PA-ZZ/PH-ZZ E(1)2A-ZZZ R(1)2A-ZZZ
24-Hr Emerg. (non-medical) QA-ZZ/QH-ZZ E(1)A1-ZZZ R(1)A1-ZZZ
24-Hr Sprinkler SA-ZZ/SH-ZZ E(1)13-ZZZ R(1)13-ZZZ
24-Hr Water WA-ZZ/WH-ZZ E(1)54-ZZZ R(1)54-ZZZ
24-Hr Freeze ZA-ZZ/ZH-ZZ E(1)59-ZZZ R(1)59-ZZZ
24-Hr Latching UA-ZZ/UH-ZZ E(1)4A-ZZZ R(1)4A-ZZZ
Interior Delay BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Auto Verified Fire FA-ZZ/FH-ZZ E(1)1A-ZZZ R(1)1A-ZZZ
24-Hr Fire Supervisory FS-ZZ/FV-ZZ E(2)AA-ZZZ R(2)AA-ZZZ
Day Zone BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Instant Stay/Away BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
24-Hr Bell/Buzzer UA-ZZ/UH-ZZ E(1)5A-ZZZ R(1)5A-ZZZ
24-Hr Non-latching Tamper UA-ZZ/UH-ZZ E(1)4A-ZZZ R(1)4A-ZZZ
Night Zone BA-ZZ/BH-ZZ E(1)3A-ZZZ R(1)3A-ZZZ
Delayed 24-Hr Fire (Wireless) FA-ZZ/FH-ZZ E(1)1A-ZZZ R(1)1A-ZZZ
Standard 24-Hr Fire(Wireless) FA-ZZ/FH-ZZ E(1)1A-ZZZ R(1)1A-ZZZ
24-Hr CO Alarm GA-ZZ/GH-ZZ E(1)62-ZZZ R(1)62-ZZZ
* ZZ or ZZZ= zones 01-64
