Appendix A: Reporting Codes
55
Appendix A: Reporting Codes
The following tables contain Contact ID and Automatic SIA format reporting codes. For more information on reporting code formats and notes
about individual reporting codes, see programming sections [320]-[349] and [601]-[608].
Contact ID
The first digit (in parentheses) will automatically be sent by the control. The second two digits are programmed to indicate specific information
about the signal. For example, if zone 1 is an entry/exit point, you could program the event code as [34]. The central station would receive the fol-
lowing: *BURG - ENTRY/EXIT - 1 where the “1” indicates which zone went into alarm.
SIA Format - Level 2 (hard coded)
The SIA communication format used in this product follows the level 2 specifications of the SIA Digital Communication Standard - October
1997. This format will send the Account Code along with its data transmission. The transmission will look similar to the following at the receiver:
NOTE: A system event will use the Area Identifier Ri00.
Table 1: Reporting Codes/
N Ri01 =
BA 01
BA =
Burglary Alarm
N =
New Event
01 =
Zone 1
Ri01 =
Partition /Area Identifier
Section # Reporting Code Code Sent When...
Dialer
Direction*
Automatic
Contact ID
Codes
SIA Auto
Rep Codes**
[320]-[323] Zone Alarms Zone goes into alarm A/R
See
Tables 2 & 3
See Table 3
[324]-[327] Zone Restorals Alarm condition has been restored A/R
[328] Duress Alarm Duress code entered at keypad A/R E(1)21-000 HA-00
[328] Opening After Alarm System disarmed with alarm in memory A/R E(4)58-000 OR-00
[328] Recent Closing Alarm occurs within two minutes of system arming A/R E(4)59-UUU CR-00
[328] Zone Expander Supervisory
Alarm/Rest.
Panel loses/restores supervisory transmission over the Keybus from
zone expansion modules, or keypads with zone inputs
A/R E(1)43-000/
R(1)43-000
UA-00/UH-00
[328] Cross Zone (Police Code)
Alarm
Two zones on the same partition go into alarm during any given
armed-to-armed period (incl. 24Hr zones)
A/R E(1)39-000 BM-00/BV-00
[328] Burglary Not Verified This event is transmitted when a second cross-zone alarm does not
occur within the cross-zoning time
A/R E(3)78-000 BG-00
[328] Alarm Cancelled Sent when the system is disarmed after an alarm, but before the
expiry of the alarm cancellation timer
A/R E(4)A6-UUU BC-00
[329] [F] Key Alarm/Restoral Keypad fire alarm/restore (alarm and restore rep. codes sent
together)
A/R E(1)1A-000/
R(1)1A-000
FA-00/FH-00
[329] [A] Key Alarm/Restoral Keypad auxiliary alarm/restore (alarm and restore rep. codes sent
together)
A/R E(1)AA-000/
R(1)AA-000
MA-00/MH-00
[329] [P] Key Alarm/Restoral Keypad panic alarm/restore (alarm and restore rep. codes sent
together)
A/R E(1)2A-000/
R(1)2A-000
PA-00/PH-00
[329] Aux Input Alarm/Rest Option#23/24: a panic button wired to PGM 2 is pressed/access code
is entered
Option #04: a 2-wire smoke detector wired to PGM 2 goes into alarm/
alarm is cleared.
A/R
A/R
E(1)4A-000/
R(1)4A-000
E(1)11-000/
R(1)11-000
UA-99/UH-99
FA-99/FH-99
[330]-[337] Zone Tamper/Restoral Zone is tampered / tamper condition restored T/R E(3)83-ZZZ/
R(3)83-ZZZ
TA-ZZ/TR-ZZ
[338] General System Tamper/
Rest.
Enrolled module with tamper inputs has a tamper alarm/all module
tampers restored
T/R E(1)45-000/
R(1)45-000
ES-00/EJ-00
[338] Keypad Lockout Max. number of incorrect access codes has been entered at a
keypad
T/R E(4)61-000 JA-00
[339-341] Closings System armed (user 01-32 indicated) O/C R(4)A1-UUU CL-UU
[341] Partial Closing One or more zones bypassed when system armed O/C E(4)56-000 CG-00
[341] Special Closing Closing (arming) using one of the following methods: quick arm, auto
arm, keyswitch, function key, maintenance code, DLS software,
wireless key
O/C R(4)AA-000 CL-00
[341] Late to Close Whenever the Auto-arm prealert sounds (if the Late to Close option is enabled) O/C R(4)54-000 CI-00
[341] Exit Fault The Exit Fault pre-alert occurs and Entry Delay expires O/C E(3)74-ZZZ EE-00
[341] Zone Bypass Zone is bypassed O/C E(5)7A-ZZZ UB-ZZ
[342-344] Openings System disarmed (user 01-32 indicated) O/C E(4)A1-UUU OP-UU
[344] Auto-arm Cancellation Auto-arm cancelled O/C E(4)55-000 CI-00
[344] Special Opening Opening (disarming) using one of the following methods: keyswitch,
maintenance code, DLS software, wireless key
O/C E(4)AA-000 OP-00
[345]-[346] Battery Trouble/Rest. PC1616/PC1832/PC1864 battery is low/battery restored MA/R E(3)A2-000/
R(3)A2-000
YT-00/YR-00
[345]-[346] AC Line Trouble/Rest. AC power to control panel is disconnected or interrupted/AC power
restored (Both codes follow AC Failure Comm. Delay.)
MA/R E(3)A1-000/
R(3)A1-000
AT-00/AR-00
[345]-[346] Bell Circuit Trouble/Rest. Open or short circuit detected across bell terminals/bell circuit
restored
MA/R E(3)21-000/
R(3)21-000
YA-99/YH-99
[345]-[346] Fire Trouble/Rest. Trouble occurs/restores on a fire zone MA/R E(3)73-000/
R(3)73-000
FT-99/FJ-99
[345]-[346] Auxiliary Power Trouble/Rest. Aux voltage supply trouble/restoral MA/R E(3)12-000/
R(3)12-000
YP-00/YQ-00
To Next Page
