Appendix E: Template Programming
Template programming allows quick programming of the minimum functions required for basic operation. The below tables are used to determine the desired template to
be used (for information on performing template programming see Section 4 – Programming Descriptions). Each digit represents 1 of the template sections listed below.
The option number selected for each digit will make up the 5 digit template programming code.
• Digit 1 selects Zone 1-8 definition options
Digit 1 selects 1 of the following 6 options for zone definitions for the first 8 zones. A “0” in the digit 1 location indicates that the default settings for the first
8 zones are in place unless overridden. See Sections [001] to [004] on pages 30-31 for defaults.
• Digit 2 selects system EOL configuration options
• Digit 3 selects panel communications options
• Digit 4 selects reporting code configurations
Common Group
Option Zn1 Zn2 Zn3 Zn4 Zn5 Zn6 Zn7 Zn8 1 Delay 1
1 13334444
2 Delay 2
2 13355558
3 Instant
3 13355557
4 Interior
4 11333333
5 Interior Stay/Away
5 13365555
6 Delayed Stay/Away
6 13365558
7 Delayed 24-Hour Fire
Refer to Section 4 for Zone definition details 8 Standard 24-Hour Fire
Option [013] Opt 1 [013] Opt 2
1 NC Loops ON OFF
2 SEOL OFF OFF
3DEOL OFF ON
Option Phone Line 1 Programming Section Phone Line 2 Programming Section
1 Disabled [380] Opt 1 OFF Disabled [380] Opt 1 OFF
2
SIA automatic Reporting Codes enabled [350] 1st Phone # [04]
[380] Opt 1 ON
[381] Opt 3 OFF
SIA automatic
Reporting Codes
enabled
[350] 2nd Phone # [XX]
3
Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON
[381] Opt 7 OFF
SIA automatic
Reporting Codes
enabled
[350] 2nd Phone # [XX]
4
SIA automatic Reporting Codes enabled [350] 1st Phone #[04]
[380] Opt 1 ON
[381] Opt 3 OFF
Residential Dial
Enabled
[350] 2nd Phone # [06]
5
Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON / Opt 7
OFF
Residential Dial
Enabled
[350] 2nd Phone # [06]
6
Contact ID Reporting Codes enabled [350] 1st Phone # [03]
[380] Opt 1 ON
[381] Opt 7 OFF
Contact ID Reporting
Codes Enabled
[350] 2nd Phone # [03]
Option
Common
Group
Selected
Troubles
Openings/
Closings
Zone
Restorals
DLS/Installer
Lead In/Out
1
2
3
4
5
6
7
8
indicates included, Blank indicates default setting, indicates disabled
Description Phone 1 Phone 2 Sections
Set all Reporting Codes to automatic [320] - [349], [601] - [608] FF
Alarm/Restore call directions enabled
[351][1] ON, [2] OFF
Tamper/Restore Call directions disabled
[359][1] OFF, [2] OFF
Opening/Closing Call directions disabled
[367][1] OFF, [2] OFF
Maintenance Call Directions enabled
[375][1] ON, [2] OFF
Test Transmission Call directions disabled
[376][1] OFF, [2] OFF
