DSC PowerSeries PC1616 Installation Guide

PowerSeries - PC1616/PC1832/PC1864
64
Selected Troubles
Openings & Closings
Zone Restorals
DLS/Installer Lead IN/OUT
• Digit 5 selects DLS connection options.
Trouble [345] Alarms [346] Restoral
Battery
FF FF
AC Failure
00 00
Bell Circuit
FF FF
Fire, Alarm
FF FF
Aux PS
FF FF
TLM
00 FF
General System
00 00
General System Supervisory
FF FF
FF = Communicate in automatic format , 00 = Disabled
Users CLOSINGS, Residential Dial Reporting codes Section
1-8
51 52 53 54 55 56 57 58 [339]
9-16
61 62 63 64 65 66 67 68 [339]
17-24
71 72 73 74 75 76 77 78 [340]
25-32
81 82 83 84 85 86 87 88 [340]
33-40
FF FF FF FF FF FF FF 98 [601]
Users OPENINGS, Residential Dial Reporting codes Section
1-8
11 12 13 14 15 16 17 18 [342]
9-16
21 22 23 24 25 26 27 28 [342]
17-24
31 32 33 34 35 36 37 38 [343]
25-32
41 42 43 44 45 46 47 48 [343]
33-40
FF FF FF FF FF FF FF 98 [605]
Enable Opening/Closings call directions for Phone 2
[367]
Zones Alarm Restoral Reporting Codes Section
1-64
00 00 00 00 00 00 00 00
[324]-[327]
00 = Disabled
Miscellaneous Maintenance Reporting Codes Section
DEF DEF DEF 00 00 DEF DEF DEF DEF DEF 00 00
[347]
DEF = No change to default values, 00 = Disabled
Option Programming Section DLS Connection/Call back setting
1 [401] Option 1 OFF
Option 3 OFF
[406] 0
Double Call Disabled, Call Back Disabled
Number of rings to answer on set to 0
2 [401] Option 1 ON
Option 3 OFF
[406] 9
Double Call Enabled, Call Back Disabled
Number of rings to answer on set to 9
3 [401] Option 1 ON
Option 3 ON
[406] 9
Double Call Enabled, Call Back Enabled
Number of rings to answer on set to 9

DSC PowerSeries PC1616 Specifications

General

Partitions	2
Keypads	Up to 8
Zones	6 on-board
PGMs	2
Power Supply	16.5VAC
Battery Backup	12VDC, 4Ah
