PowerSeries - PC1616/PC1832/PC1864
32
Programmable Output Options
01 Residential Burglary and Fire Bell Output 18 Stay Armed Status 36 Zone Follower Output (Zones 17-24)
02 For Future Use 19 Command Output #1 ([*][7][1]) 37 Zone Follower Output (Zones 25-32)
03 Sensor Reset [*][7][2] 20 Command Output #2 ([*][7][2]) 38 Zone Follower Output (Zones 33-40)
04 2-Wire Smoke Support (PGM 2 only) 21 Command Output #3 ([*][7][3]) 39 Zone Follower Output (Zones 41-48)
05 System Armed Status 22 Command Output #4 ([*][7][4]) 40 Zone Follower Output (Zones 49-56)
06 Ready To Arm 23 24-hr Silent Input (PGM 2 only) 41 Zone Follower Output (Zones 57-64)
07 Keypad Buzzer Follow Mode 24 24-hr Audible Input (PGM 2 only)
08 Courtesy Pulse 25 Delayed Fire and Burglary Output
09 System Trouble Output (with Trouble options) 26 Battery Test Output
10 System Event (Strobe with Event options) 28 Holdup Output
11 System Tamper (all sources) 29 Zone Follower Output (Zones 1-8)
12 TLM and Alarm 30 Partition Status Alarm Memory
13 Kissoff Output 31 Alternate Communicator
14 Ground Start Pulse 32 For Future Use
15 Remote Operation (DLS Support) 33 For Future Use
16 For Future Use 34 Away Armed with no Zone Bypassed Status
17 Away Armed Status 35 Zone Follower Output (Zones 9-16)
[010] PGM3 to PGM10 Output Programming (Main Panel/PC5208)
Program PGM Option Attributes in sections [501] - [514]. Program PGM partitions in sections [551] - [564]
Default Default
01
I_______I_______I PGM 3 (main panel/PC5208)* 01 I_______I_______I PGM 7 (PC5208)
01
I_______I_______I PGM 4 (main panel/PC5208)* 01 I_______I_______I PGM 8 (PC5208)
01
I_______I_______I PGM 5 (PC5208) 01 I_______I_______I PGM 9 (PC5208)
01
I_______I_______I PGM 6 (PC5208) 01 I_______I_______I PGM 10 (PC5208)
These two sections above allow you to program both PGM3 and PGM4 on the main panel, and the first two PGM outputs on the
PC5208. If you use both the main panel and the PC5208 outputs, PGM3 will work identically to the first PC5208 output, and PGM4
will work identically to the second PC5208 output.
[011] PGM 11 to PGM 14 Output Programming (PC5204)
Program PGM Option Attributes in sections [501] - [514]. Program PGM partitions in sections [551] - [564]
Default Default
01
I_______I_______I PGM 11 01 I_______I_______I PGM 13
01
I_______I_______I PGM 12 01 I_______I_______I PGM 14
Other System Options
[012] Keypad Lockout Options
If Keypad Lockout is active, the panel cannot be disarmed with a keyswitch.
Default
000 I_______I_______I_______I Number of Invalid Codes Before Lockout (001-255 codes, 000 to disable)
000 I_______I_______I_______I Lockout Duration (000-255 minutes)
[009] PGM1 and PGM2 Output Programming (Main Panel)
Program PGM Option Attributes in sections [501] - [514]. Program PGM partitions in sections [551] - [564].
PC1616 and PC1832 have 2 onboard PGMs (PGM 1 and 2). PC1864 has 4 on-board PGMs (PGM 1-4).
Default Default
19 I_______I_______I PGM 1 10 I_______I_______I PGM 2
Output types [03], [04]
and [20] cannot be used
together on the same
system.
