Description of Controls
17
5 DESCRIPTION OF CONTROLS
The following section details the function and meaning of the various controls on the module.
Common Alarm
Indicator
Toggle S2 load
switch
Display Scroll button
Toggle S1 load
switch
Select auto
Mode
Main status display
Select Stop
Select Manual Mode
Select Mode
Info button
