Specification
9
3.4 INPUTS
3.4.1 DIGITAL INPUTS
Number 9 Negative 1 Positive switching.
Arrangement Contact between input terminal and the module’s plant supply negative / positive
terminal
Low level threshold 3.2V minimum
High level threshold 8.1V maximum
Maximum input voltage +60V DC with respect to module’s plant supply negative terminal
Minimum input voltage -2V DC with respect to module’s plant supply negative terminal
Contact wetting current 7mA ±1mA
Open circuit voltage 12V ±1V
3.5 OUTPUTS
3.5.1 S1 / S2 LOADING OUTPUTS A & B
Number 2 (Configurable outputs A & B)
Type Volts free contacts. Output C Normally closed, Output D Normally open
Rating 8A 250V AC resistive
3.5.2 START/RUN OUTPUT C
Number 1 (Configurable output C)
Type Volts free normally closed contact
Rating 8A @ 35V
3.5.3 CONFIGURABLE OUTPUTS D & E
Number 2 (Configurable outputs D & E)
Type Fully configurable, volts free relays. D=change over, E=normally open
Rating 8A @ 250V AC resistive
Protection Protected against over current & over temperature. Built in load dump feature.
3.6 COMMUNICATION PORTS
USB Port USB2.0 Device for connection to PC running DSE configuration suite only
