Description of Controls
24
5.3 CONTROLS
5.3.1 MODE SELECTION
This button places the module into its ‘Automatic’ mode. This mode allows the module to control the
function of the load switching completely automatically. The module monitors the remote start input and
S1 supply status and once a start request is made,S2 is placed on load.
Upon removal of the starting signal (or the S1 supply returns), the module will automatically transfers the
load from S2 to the S1.
For further details, please see the more detailed description of ‘Auto operation’ elsewhere in this manual.
Stop
This button places the module into its Stop mode preventing the module from transferring over to S2 on
a S1 fail or prevent a start request if using a generator.
Once in Test on load mode the module sends a start request to the generator and places the set on
load. The set remains on load when in this mode.
This mode allows manual control of the ATS functions. Once in Manual mode the module sends a start
request to the generator if selected.
Breakers are opened and close using the transfer buttons detailed below.
5.3.2 DISPLAY
This button changes between the various pages About, Status, Instrumentation, Alarms, Event Log, LCD
Indicators
This buttons scrolls through the items in the currently displayed page.
5.3.3 LOAD SWITCHING CONTROL
Two fascia mounted buttons are provided for load switching operation when in manual mode. These buttons are
enabled/disabled in the modules PC configuration Suite so refer to your configuration file to ensure the configuration
has enabled the buttons.
Pressing this button when S1 is on load opens the S1 load switch.
Pressing this button when S2 is on load and the S1 is healthy, opens S2 load switch, waits for the
duration of the transfer delay, then closes S1 load switch.
Pressing this button when S2 is on load opens S2 load switch.
Pressing this button when S1 is on load and S2 is available, will open S1 load switch, waits for the
duration of the transfer delay, then closes S2 load switch.
