DSE DSE331 - Page 30

Front Panel Configuration
30
CONFIGURATION PARAMETERS – INPUTS (Page 3)
301 Digital Input A Source 0 (Input Source List)
302 Digital Input A Polarity 0 (Input Polarity List)
303 Digital Input B Source 0 (Input Source List)
304 Digital Input B Polarity 0 (Input Polarity List)
305 Digital Input C Source 0 (Input Source List)
306 Digital Input C Polarity 0 (Input Polarity List)
307 Digital Input D Source 0 (Input Source List)
308 Digital Input D Polarity 0 (Input Polarity List)
CONFIGURATION PARAMETERS – OUTPUTS (Page 4)
401 Digital Output A Source 0 (Output Source List)
402 Digital Output A Polarity 0 (Output Source Polarity)
403 Digital Output B Source 0 (Output Source List)
404 Digital Output B Polarity 0 (Output Source Polarity)
405 Digital Output C Source 0 (Output Source List)
406 Digital Output C Polarity 0 (Output Source Polarity)
407 Digital Output D Source 0 (Output Source List)
408 Digital Output D Polarity 0 (Output Source Polarity)
409 Digital Output E Source 0 (Output Source List)
410 Digital Output E Polarity 0 (Output Source Polarity)
411 Digital Output F Source 0 (Output Source List)
412 Digital Output F Polarity 0 (Output Source Polarity)
413 Digital Output G Source 0 (Output Source List)
414 Digital Output GPolarity 0 (Output Source Polarity)
415 Digital Output H Source 0 (Output Source List)
416 Digital Output H Polarity 0 (Output Source Polarity)
CONFIGURATION PARAMETERS – TIMERS (Page 5)
501 S1 Transient Delay 509 Breaker trip pulse
502 Start Delay 510 Return delay
503 Warming time 511 Cooling time
504 S2 Fail delay 512 S2 transient delay
505 Elevator Delay 513 Fail to stop enable
506 Non-sync transfer time 514 Fai to stop delay
507 Check sync transfer time 515 LCD Page timer
508 Breaker close pulse 516 LCD Scroll timer
CONFIGURATION PARAMETERS – S1 (Page 6)
601 Immediate S1 dropout On (1), Off (0)
602 AC system 0 (AC System)
603 Under voltage enable On (1), Off (0)
604 Under voltage trip 0 V
605 Under voltage return 0 V
606 Over voltage enable On (1), Off (0)
607 Over voltage return 0 V
608 Over voltage trip 0 V
609 Under frequency enable On (1), Off (0)
610 Under frequency trip 0.0 Hz
611 Under frequency return 0.0 Hz
612 Over frequency enable On (1), Off (0)
613 Over frequency return 0.0 Hz
614 Over frequency trip 0.0 Hz
