DSE DSE331 - Page 31

Front Panel Configuration
31
CONFIGURATION PARAMETERS – S2 (Page 7)
701 Immediate S2 dropout On (1), Off (0)
702 Under voltage enable (Generator Option) On (1), Off (0)
703 Under voltage trip (Generator Option) 0 V
704 Loading voltage (Generator Option) 0 V
705 Over voltage enable (Generator Option) On (1), Off (0)
706 Over voltage trip (Generator Option) 0 V
707 Under frequency enable (Generator Option) On (1), Off (0)
708 Under frequency trip (Generator Option) 0.0 Hz
709 Loading frequency (Generator Option) 0.0 Hz
710 Over frequency enable (Generator Option) On (1), Off (0)
711 Over frequency trip (Generator Option) 0.0 Hz
712 Under voltage enable (Mains Option) On (1), Off (0)
713 Under voltage (Mains Option) 0 V
714 Under voltage return (Mains Option) 0 V
715 Over voltage enable (Mains Option) On (1), Off (0)
716 Over voltage return (Mains Option) 0 V
717 Over voltage trip (Mains Option) 0 V
718 Under frequency enable (Mains Option) On (1), Off (0)
719 Under frequency (Mains Option) 0.0 Hz
720 Under frequency return (Mains Option) 0.0 Hz
721 Over frequency enable (Mains Option) On (1), Off (0)
722 Over frequency return (Mains Option) 0.0 Hz
723 Over frequency trip (Mains Option) 0.0 Hz
CONFIGURATION PARAMETERS – PLANT BATTERY (Page 8)
801 Under voltage enable On (1), Off (0)
802 Under voltage 0.0 V
803 Under voltage return 0.0 V
804 Under voltage delay 0.00.00
805 Over voltage enable On (1), Off (0)
806 Over voltage return 0.0 V
807 Over voltage trip 0.0 V
808 Over voltage delay 0.00.00
CONFIGURATION PARAMETERS – SCHEDULER (Page 9)
901 Enable scheduler On (1), Off (0)
902 On or off load On (1), Off (0)
903 Start time 0:00
904 Day 1-7 (Day, 1=Monday)
905 Duration 0:00
CONFIGURATION PARAMETERS – TIME (Page 10)
1001 Time of day 0:00
1002 Day of week 1-7 (Day, 1=Monday)
1003 Start time 0:00
