Front Panel Configuration
32
Parameters with multiple choices use the following identification tables for the parameter values:
INPUT SOURCE LIST
0 Not used
1 Alarm Reset
2 Alarm Mute
3 Auto Restore Inhibit
4 Auto Start Inhibit
5 Auxiliary S2 Available
6 Auxiliary S1 Fail
7 S2 Load Inhibit
8 S2 Closed Auxiliary
9 Inhibit Scheduled Run
10 Lamp Test
11 Load Shedding
12 S1 Closed Auxiliary
13 S1 Load Inhibit
14 Open / Close S2
15 Open / Close S1
16 Panel Lock
17 Remote Start off-load
18 Remote Start on-load
19 Simulated S1 available
20 Simulated S2 available
INPUT POLARITY LIST INPUT ARMING LIST
Index Action Index Arming
0 Close to Activate 0 Always
1 Open to Activate 1 From Safety On
2 From Starting
OUTPUT POLARITY LIST
3 Never
Index Arming
0 Energise
INPUT ACTION LIST
1 De-energise
Index Action
0 Electrical Trip
AC SYSTEM
1 Shutdown
Index Type
2 Warning
0 3 phase 4 wire
1 Single phase 2 wire
2 3 phase 3 wire
3 2 phase 3 wire (L1-L2)
4 2 phase 3 wire (L1-L3)
5 3 phase 4 wire (Delta)
