Front Panel Configuration
33
OUTPUT SOURCE LIST
0 Not Used
1 Audible Alarm
2 Battery High Voltage
3 Battery Low Voltage
4 Close S2 Output
5 Close S2 Output Pulse
6 Close S1 Output
7 Close S1 Output Pulse
8 Close to N Output
9 Close to N Output Pulse
10 Common Warning
11 Cooling Down
12 Digital Input A
13 Digital Input B
14 Digital Input C
15 Digital Input D
16 Elevator Control
17 Fail to start
18 Fail to stop
19 Fail to reach loading voltage
20 Fail to reach loading frequency
21 S2 Available
22 S2 Failure Latched
23 S2 Failure Unlatched
24 S2 In Limits
25 S2 Load Inhibited
26 S2 ready
27 S1 Failure unlatched
28 S1 Failure latched
29 S1 High Frequency
30 S1 High Voltage
31 S1 In Limits
32 S1 Load Inhibited
33 S1 Low Frequency
34 S1 Low Voltage
35 Return Delay
36 Open S2 Output
37 Open S2 Output Pulse
38 Open S1 Output
39 Open S1 Output Pulse
40 Scheduled Run
41 Start And Run S2
42 Start Delay
43 Waiting For S2
44 Waiting For Manual Restore
45 Warming Up
