7.2. Managing the programming environment

Created YIM folder in the SD card can be stored in the host PC by using AZ990 (air Connect). You can

re-create the same programming environment by transferring the saved YIM folder to another working

environment.

This chapter explains how to save the YIM folder, and how to load it.

Same definition programming license is required in the destination SD card if you want to share the

same programming environment with more than one SD card by transferring YIM folder.

7.2.1 How to save YIM folder (Operation for the original folder)

(1) Right-click the folder.

(2) Select Upload YIM Folder from the

pop-up menu.

(4) Specify where to save the

folder on PC.

(5) Click OK button.

(3) Select the YIM folder you want to transfer.
