Ducati MONSTER 821 - Removing the Battery

Removing the battery
Important
When battery must be removed, ALWAYS
contact a Ducati Dealer or authorised Service Centre.
Loosen the screw (1) and remove the cover (2).
Loosen screws (3) and (4), and remove cover (5), pay
attention to the canister (6) since it is fitted on the
same cover.
Remove canister (6) from cover (5) disengaging
rubber band (7) from its retainer: leave canister
connected to vehicle.
2
4
5
3
1
Fig. 181
6
7
5
Fig. 182
240
