Engine
90° L-type twin-cylinder - 4-stroke Otto cycle engine -
with high sump die-cast crankcase
Bore:
88 mm (3.46 in)
Stroke:
67.5 mm (2.66 in)
Total displacement, cu.
cm (cuin): 821.1 (50.10)
Compression ratio: 12.8±0.5
Maximum power at crankshaft (EU) Regulation no.
134/2014 Annex X, kW/CV (kW/HP):
80 kW - 109 CV at 9250
rpm (80 kW / 107 HP at 9250
rpm)
Maximum torque at crankshaft (EU) Regulation no.
134/2014, Annex X, Nm / Kgm (Nm / lbf ft):
86 Nm - 8.7 Kgm at 9250
rpm (86 Nm / 63.43 lbf ft at
9250 rpm)
Important
The specified power/torque values have been
measured on a dyno bench. The power/torque values
measured upon type-approval and specified on the
vehicle log-book are measured by means of a static
test bench according to the type-approval regulations.
The two values indicated for power/torque could
hence differ because of the different measurement
devices used.
Maximum
rpm:
10,500
Important
Do not exceed the specified rpm limits in any
running conditions.
277
