Residual range (RANGE)
This function displays the range according to the
remaining fuel in the tank.
Information is indicated as RANGE, in the set unit of
measurement.
If there is any function fault, the instrument panel will
display three flashing dashes "- - -".
If the instrument panel is not receiving RANGE
information, a string of three steady dashes "- - -" is
displayed, followed by the unit of measurement.
Note
If the instrument panel does not receive any
information on the unit of measurement, the last unit
of measurement set is displayed flashing.
Considering that the TRACK and FULL layouts show
the values for this function in a similar way to the
CORE layout, the example shown depicts the
function in CORE layout.
299
N
LAP
SPORT
98
6
5
4
3
2
1
7
10
11
km/h
RPM x 1000
DTC 1
ABS 1
9999.9
RANGE Km
TRACK
Fig. 28
71
