Brakes
Separate-action anti-lock brake system operated by
hall-type sensors mounted to each wheel with phonic
wheel detection: ABS can be disabled.
Front
Type: with drilled steel disc.
no. 2 discs.
Disc diameter: 320 mm (12.60 in).
Hydraulically operated by a control lever on handlebar
right-hand side.
Monoblock brake callipers with separate pistons.
Make and type: Brembo M4.32 b.
Friction material: Toshiba TT2182FF.
Master cylinder type:
PS 16/22.
Cylinder Ø: 16 mm (0.63 in).
Rear
Type: with fixed drilled steel disc.
Disc diameter: 245 mm (9.64 in).
Hydraulically operated by a pedal on RH side.
Brake calliper: 2 pistons Ø34 mm (1.34 in).
Make and type: Brembo M4.32b.
Friction material: Toshiba TT2172 HH.
Master cylinder type: PS 11/34.
Cylinder Ø: 11 mm (0.43 in).
Warning
The brake fluid used in the brake system is
corrosive.
In the event of accidental contact with eyes or skin,
wash the affected area with abundant running water.
280
